Texecom Capture P15 — Specs & Hong Kong Installation

15 m / 90° Grade 2 wall PIR with optional PetWise mode.

Best for: Rooms / corridors

Product overview

The Texecom Capture P15 is a pir motion detector from the Capture series, selected by Swan CCTV for professional projects across Hong Kong and Macau. 15 m / 90° Grade 2 wall PIR with optional PetWise mode. It is best suited for rooms / corridors.

Capture P15 is used as a detection point in a Texecom intrusion system. Correct placement matters in Hong Kong interiors: narrow corridors, glass shop fronts, and high-mounted air-conditioners can create false alarms if sensors are aimed poorly. Our technicians mount and walk-test each detector against furniture layouts and pet traffic where applicable.

We commonly pair this device with hybrid or wireless Texecom panels for apartments, retail stores, and back-of-house areas. Installation includes zone naming in Chinese/English on the keypad where required, so staff can understand which door or area triggered an alert.

Compared with generic online product listings, this page reflects how Swan CCTV actually deploys Capture P15 on local sites: we confirm power availability, building management rules, false-alarm risk, and monitoring options before quoting. Request a site survey if you need a tailored bill of materials.

Key features

Front-loaded sealed electronics — less dust, insect, and static damage
Digital temperature compensation and white-light rejection
Selectable creep zone on wall models
Same housing as Capture dual-tech and wireless variants
Professional supply and installation by Swan CCTV in Hong Kong
Configured and tested on-site (not leave-in-box DIY)
Documentation and user training included with installation packages

Compatibility

Designed for use within Texecom Capture ecosystems and compatible accessories stocked by Swan CCTV.
Pairs with Texecom control panels that accept this sensor family (wired or wireless as specified).
Compatible with standard EOL resistors and zone programming practices used on our Hong Kong projects.
Often quoted together with: Premier Elite 24, Premier Elite 48, Premier Elite 88, Premier Elite 168.

Manuals, datasheets & resources

Capture P15 specifications Browse Texecom manuals in Knowledge Base

Technical specifications

Coverage	15 m / 90° volumetric
Sensor	Dual-element pyro
Pet immunity	Optional PetWise (up to ~10 m catch in pet mode; 35 kg class on DT PetWise models)
Mounting height	1.5–3.0 m
LED	Cyan walk-test LED
Standards	EN 50131-2-2 / PD6662:2017 Grade 2
Part codes	White AKB-0001 / Black AKB-0006
Wiring	Built-in selectable EOL resistors
Brand	Texecom
Series	Capture
Category	PIR Motion Detector
Local support	Supply, install, program, and after-sales by Swan CCTV (Hong Kong)
Typical use	Rooms / corridors

Hong Kong / local context

Hong Kong properties often combine aluminium windows, metal gates, compact rooms, and mixed residential-commercial use. Swan CCTV selects Capture P15 when its zone capacity, detection pattern, or video performance matches those constraints.

Door contacts are fitted to typical HK metal gates and frame types; glass-break and PIR placement accounts for small rooms and reflective surfaces.

Ask Swan CCTV for a Hong Kong site survey if you are comparing Capture P15 with other Texecom models for your layout.

Installation notes

Swan CCTV provides supply, mounting, programming, and testing for Capture P15 as part of a complete Texecom system.
A short site survey confirms cable routes, Wi-Fi/4G signal, power points, and building management constraints before installation day.
Mounting height and angle are set to reduce false alarms from curtains, A/C airflow, and pets where possible.
Each zone is walk-tested and named clearly on the keypad or app.
Warranty and manufacturer support terms follow the official Texecom policy; Swan CCTV provides local labour warranty on our workmanship as stated in your quotation.
